CYLINDER ASS’Y D65PX-12
| 14Y-63-01014 | CYLINDER ASS’Y | |
| 1 | 14Y-63-12144 | CYLINDER,L.H. |
| 2 | 707-29-95730 | HEAD,CYLINDER |
| 3 | 707-52-10660 | BUSHING |
| 4 | 707-51-65211 | PACKING,ROD (KIT) |
| 5 | 07000-02095 | O-RING (KIT) |
| 6 | 07000-12090 | O-RING (KIT) |
| 7 | 707-35-52780 | RING,BACK-UP (KIT) |
| 8 | 144-63-92170 | SEAL,DUST (KIT) |
| 9 | 07179-12079 | RING,SNAP |
| 10 | 14Y-63-12121 | ROD,PISTON |
| 11 | 707-66-70020 | CAP |
| 12 | 01011-51600 | BOLT |
| 13 | 01643-51645 | WASHER |
| 14 | 707-88-11290 | SHIM¤ 1.0MM |
| 707-88-11300 | SHIM¤ 0.5MM | |
| 14Y-63-12131 | PISTON SUB ASS’Y | |
| 15 | 707-37-95010 | PISTON |
| 16 | VALVE,PISTON | |
| 17 | VALVE,PISTON | |
| 18 | VALVE,PISTON | |
| 19 | SEAT,VALVE | |
| 20 | 707-44-95180 | RING,PISTON (KIT) |
| 21 | 707-69-95010 | SLIDER |
| 22 | 707-39-95120 | RING,WEAR (KIT) |
| 23 | 130-63-12761 | PIN,DOWEL |
| 24 | 707-40-95010 | RETAINER |
| 25 | 707-68-10330 | NUT |
